MAX-18-Compact
Our shortest version of the MAX extruders. With a total length of just app. 450 mm and a side-mounted power cable, it's ideal for even the tightest spaces. Almost as light and quiet as the MAX-18, it also features a 360° rotating welding shoe and a continuously adjustable handle. With this digitally controlled extruder, you can effortlessly weld material up to 15 mm or even 20 mm thick. Integrated high-performance LEDs ensure good illumination in the work area. When not in use, the device goes into standby mode, significantly reducing noise levels and saving up to 50% energy. Once the device has completely cooled down, the fan switches off completely.
- Length-optimized design for particularly narrow applications
- Brushless preheating blower with standby-function and automatic shut-down
- Comfortable user menu with automatic temperature setting
- Dual beam high-power LEDs
- Three materials preset, more program spaces free to set your own material
- 360° turnable welding shoe
- With display / menu
- Temperatures digitally adjustable
- WiFi-connectivity
| Max. welding capacity: | 2.2 kg/h, Ø 4mm 1.3 kg/h, Ø 3 mm |
| Welding material: | PP / PE / PVDF |
| Material type: | Round rod Ø 3 / 4 mm |
| Application range: | Thicknesses from 4 – 20 mm |
| Weight: | 5.5 kg |
| Length: | 460 mm |
| Electronic Speedcontrol: | yes |
| Mass heating: | 400 W |
| Powerbox needed: | No |
| Preheating: | 2300 W |
| Frequency: | 50Hz & 60HzW |
This item is available in 115 or 230V.
We include for free:
- 1 welding shoe fillet 10mm(G07684)
- 1 welding shoe film 25mm (G07680)
- 1 welding shoe unshaped (G07692)
- Machine stand
- Tool and maintenance kit
- Transport case
